Nanocrystalline Transfomer Core

Using nanocrystalline (saturation flux density 1.2-1.5T), eddy current losses are reduced by over 60% compared to ferrite, supporting high-frequency applications (20kHz–1MHz), suitable for switching power supplies and inverters.


High-Frequency Transformer Nanocrystalline Core















High-Frequency Low-Loss Characteristics
Utilizing nanocrystalline material (saturation magnetic flux density 1.2-1.5 T), eddy current losses are reduced by over 60% compared to ferrite. Supports high-frequency scenarios from 20 kHz to 1 MHz, meeting the demands of switching power supplies and inverters.

High Permeability and Precision
Initial permeability reaches 8×10⁴ Gs/Oe. Combined with optimized core air gap design, current sampling linearity error is controlled within ±0.2%, meeting high-precision applications like smart meters.

Wide Temperature Stability
Operating temperature range spans -40°C to +180°C. Magnetic permeability decay rate remains <10% at high temperatures, outperforming traditional silicon steel and ferrite cores.

Miniaturization and Lightweight Design
The nanocrystalline core reduces volume by 50% and weight by 60%, making it ideal for space-constrained applications like new energy vehicles and portable devices.














Type Core Size (mm) Shell Size (mm) Cross-sectional area
(cm2)		 Magnetic length Weight Suitable For inverter welding power sources
(KW)		 Suitable inverter welding machine output current (A)
OD ID H OD ID H (cm) (g)
ZH-503220 50 32 20 54 28 24 1.35 12.87 125
ZH-644020 64 40 20 66 37 23 1.8 16.34 213 2-5
ZH-704025 70 40 25 72 37 28 2.81 17.28 352 3
ZH-755025 75 50 25 77 47 28 2.34 19.63 334 4.5
ZH-805020 80 50 20 82 46 23 2.25 20.42 333 4
ZH-805025 80 50 25 85 44 30 2.81 20.42 416 5 120A 160A
ZH-904020 90 40 20 / / / 3.75 20.42 555 10
ZH-1005025 100 50 25 105 44 30 4.69 23.56 801 12
ZH-1006020 100 60 20 105 56 23 3 25.13 547 8 160A 200A
ZH-1206030 120 60 30 125 57 35 6.75 28.27 1384 15 315A
ZH-1207020 120 70 20 125 67 25 3.75 29.85 812 10
ZH-1207025 120 70 25 125 67 30 4.69 29.85 1014 12 200A 250A
ZH-1207030 120 70 30 125 67 35 5.63 29.85 1217 15 315A 400A
ZH-1308040 130 80 40 136 76 45 7.5 32.99 1793 25 400A 500A
ZH-1308050 130 80 50 136 76 55 9.38 32.99 2242 30 500A 630A
ZH-1309050 130 90 50 136 85 56 7.5 34.56 1880 30 630A
ZH-1308060 130 80 60 136 85 66 11.25 32.99 2690 40 630A
ZH-18011060 180 110 60 186 105 66 15.75 45.55 5202 60 1250A









Basic parameters Nano core Ferrite core
Saturation Magnetostrictive Induction Bs(T) 1.25 0.5
Residual Magnetic Field Density Br (T) (20KHz) <0.20 0.2
Magnetic Loss (20KHz, 0.2T) (W/kg) <3.4 7.5
Magnetic Loss (20kHz, 0.5T) (W/kg) <35 /
Magnetic Loss (20kHz, 0.3T) (W/kg) <40 /
Permeability (20kHz) (Ge/Oe) >2x104 2x103
Coercive Force (A/m) <1.60 6
Saturation Magnetostrictive Coefficient 位s <2x10-6 4x10-6
Resistivity  (µΩcm) 80 1X106
Curie Temperature (°C) 570 <200
Operating Efficiency >0.70 ---
Note: Customization is available upon request. Feel free to contact us anytime.
